Casio QV-3500EX Service Manual & Parts Catalogue

MAIN BODY COMPONENT
N Item Code No. Parts Name Specification Applicable Q Price Code R
1 1001 5687 LENS UNIT K342105*1 TK(K716)
Common 1 EJ A
2 1001 5690 DISPLAY ASSY K342106*1 TK(K716)
Common 1 CW B
2-1 6614 4530 FRAME/DISPAY K241200-1
Common 1 AC X
2-2 1001 1751 PANEL/DISPLAY K441760B-1
Common 1 AI B
2-3 1001 2616 TFT-LCD MODULE COD18T1035FN
Common 1 DE B
2-4 6614 4540 SPACER/BACK LIGHT K441763-1
Common 1 AA X
2-5 1001 5719 BL ASSY K342102*1 TK(K716)
Common 1 BV B
2-6 3851 2113 LAMP/FLUORESCENT CAS-1.8JS1.8-1
Common 1 AW A
2-7 1001 5721 PCB ASSY/BACK LIGHT K442091*1 TK(K716)
Common 1 BK C
2-8 6614 4230 TAPE/DOUBLE SIDE K441774-2
Common 2 AA X
2-9 6614 4240 TAPE/DOUBLE SIDE K441774-3
Common 2 AA X
N 3 1005 3635 PCB ASSY/DIGITAL RJK501863*001V01 TK
Common 1 EF A
4 1001 5727 PCB ASSY/KEY K342098*1 TK(K716)
Common 1 BN B
N 5 1005 3630 PCB ASSY/LED RJK501859*003V01 TK
Common 1 CT B
N 6 1005 3633 PCB ASSY/SW RJK501859*004V01 TK
Common 1 CS B
N 7 1005 3634 PCB ASSY/POWER K342100*002V06 TK
Common 1 DH A
7-1 1000 8870 CABLE/FLAT K441943-1
Common 1 AE X
7-2 1015 1467 EJECTOR UNIT/CF 55370-0011
Common 1 AY X
N 8 1005 3628 PCB ASSY/SUB K342099*003V06 TK
Common 1 CY B
N 9 1005 3632 BATTERY COVER ASSY K342097*002V02 TK
Common 1 AV B
10 1001 5702 FRAME ASSY/BT K342096*1 TK(K716)
Common 1 BA X
N 11 1004 8639 PLATE/RATING K442081-004V01
Common 1 AA X
12 1000 8856 COVER/FD-A K441951-1
Common 1 AD X
13 1000 8857 COVER/FD-B K441952-1
Common 1 AD X
14 1000 8858 COVER/SENSOR K441953-1
Common 1 AC X
N 15 1004 8638 GRIP K441954-002V01
Common 1 AD X
16 1001 1750 PANEL/DISPLAY K441761A-1
Common 1 AC X
N 17 1002 2434 BUZZER 7BB-15-6A60
Common 1 AN X
N 18 1004 8640 COVER/CF RJK501820-001V01
Common 1 AE X
N 19 1002 3200 LABEL/CF K441492-3
Common 1 AA X
20 6611 0460 PLATE/CASIO C441170-1
Common 1 AG X
N 21 1001 7425 TAPE/DOUBLE SIDE K442202A-2
Common 1 AA X
22 6601 1700 SHEET/INSULATION K4117-3
Common 5 AA X
N 23 1004 8637 COVER/CN K241206-003V01
Common 1 AE X
24 1000 8835 CASE/FD K241308-1
Common 1 AF X
N 25 1004 8625 BUTTON/MODE K341797-002V01
Common 1 AH X
26 1001 2586 CUSHION K442203-1
Common 1 AA X
N 27 1004 8622 CASE/UPPER RJK501814-001V01
Common 1 BX X
28 1000 8852 PIN/STRAP K441949-1
Common 2 AG X
29 1000 8849 KNOB/ZOOM K341852-1
Common 1 AA B
30 6614 5000 RUBBER KEY K341614-1
Common 1 AA X
31 6614 5060 SPRING/CS K441749-1
Common 1 AB X
N 32 1001 4616 BUTTON/MENU K341606-2
Common 1 AD X
N 33 1001 4617 BUTTON/SET K341607-2
Common 1 AD X
N 34 1004 8621 BUTTON/CS K341608-003V01
Common 1 AE X
N 35 1004 8623 BUTTON/POWER RJK501819-001V01
Common 1 AE X
N 36 1004 8647 CASE/LOWER RJK501795-001V01
Common 1 BV X
37 1000 8859 STROBE UNIT CO-716
Common 1 BW A
38 1000 8862 STROBE SENSOR UNIT CO-716SU
Common 1 AX C
N 39 1004 8646 COVER/LENS RJK501793-001V01
Common 1 BO X
40 6613 1210 NUT/TRIPOD K341059-1
Common 1 AC X
Notes: NEW : New registration parts
Q : Quantity used per unit
R : Rank
PARTS PRICE LIST
- 45 -
