74
The MONITOR OUT terminal of the projector outputs the video signal being input via the COMPUTER
IN 1 terminal or COMPUTER IN 2 terminal as-is. This makes it possible to simultaneously output the
projection image to another display.
Note
z The signals output from the MONITOR OUT terminal when the projector is turned on depends
on the selected input source as shown in the table below.
* For example, even if the input source is switched from Computer 1 to S-Video, the
MONITOR OUT terminal continues output the video input signal from COMPUTER IN 1.
z The projector can be configured so the input signal from the COMPUTER IN 1 terminal is
output to MONITOR OUT terminal, while the input signal from the AUDIO IN 1 terminal is
output to AUDIO OUT terminal, even if the projector is in the standby state. For details, see
“Option Settings 2 3 Standby RGB/Audio” (page 59).
Using the MONITOR OUT Terminal
When this input source is selected:
The video input signal from this terminal is output to the
MONITOR OUT terminal:
Computer 1 COMPUTER IN 1
Computer 2 COMPUTER IN 2
Video, S-Video, HDMI, File Viewer,
CASIO USB Tool, Network, USB Display
The video input signal is output from either Computer 1 or
Computer 2, in accordance with the last selected input source
(COMPUTER IN 1 terminal or COMPUTER IN 2 terminal).*
To Next Page
