79033093 D Rev. 01-15
Introduction
MACHINE IDENTIFICATION
Product Identification Information
Plate Locations
Product identification number (PIN) will be used to identify
a machine designed for an operator to ride.
Components such as engines, transmissions and major
attachments that are not designed for an operator to ride,
are identified by serial numbers.
For quick reference, record identification numbers in
spaces provided next to illustration.
FIG. 26: Machine PIN. Plate is located on left side of
frame rail.
Machine PIN: _________________________________
FIG. 27: Engine Serial Number. Plate is located on right
side of engine.
Engine Serial Number: _________________________
FIG. 28: Transmission Serial Number. Plate is located on
right rear side of transmission.
Transmission Serial Number: _____________________
FIG. 26
FIG. 27
FIG. 28
