The device is intended for the opening and closing of garage doors (please
refer to section 6 “Door Types”)� The device is not meant for commercial
use but solely for the use in private garage doors that are appropriate for a
single household� Any improper use of the drive could increase the risk of
accidents� The manufacturer assumes no liability for such usage� Only the
original accessories of Chamberlain may be connected to the drive� With this
drive, automated gates must comply with the currently valid international and
country-specic standards, guidelines and regulations (among other things,
EN 13241, EN 12453 and EN 12604)�
IMPORTANT NOTE
If your garage does not have a side entrance, an external emergency
release should be installed� This allows for manual operation of the
garage door from the outside during power failure�
First, check whether your door is balanced and in equilibrium�
Open your door about halfway and let it go�
The door can now hardly change its position independently,
but must remain in this position held by the spring force alone�
1� The rail of the garage door MUST be connected securely and rm-
ly to the supporting wall or ceiling above the garage door�
2� Additional brackets and mounting rails (not included in the supply)
might be required, if the your garage ceiling has a cladding, boards
or similar�
3� If your garage does not have a separate side entrance, an external
emergency release (refer to section 34 “Optional Accessories”)
must be installed�
A� One-Piece Door with Horizontal Track Only�
B� One-Piece Door with Horizontal and Vertical Track – Special door
arm (E, The Chamberlain Arm™) and the Protector System™
required� See your dealer�
C� Sectional Door with Curved Track – See 20B – connect door arm�
D� Canopy door – Special door arm (E, The Chamberlain Arm™) and
the Protector System™ required� See your dealer�
E� The Chamberlain Arm™ for use on door types B and D�
Please check the supplied parts for completeness before starting the in-
stallation� Note: The numbering only applies to the corresponding section�
This gure always oers you a complete overview of the readyassem-
bled system during the step by step installation of the system�
Intended use Before you begin
Door Types
Tools required
Preparation
Scope of supply
Product overview
Hardwarebag:
a� Header bracket h� Power cable
b� Belt i� Drive head
c� Rail j� Release
d� Carriage k� Straight door arm
e� Connecting piece l� Curved door arm
f� Rail bracket m� Door bracket
g� Hanging bracket
15�
Truss head screw
6 x 80 mm
1x 20� Safety cotter pin 1x
16� Lock nut M6 1x 21� Screw ST 6 x 60 mm 4x
17� Hexagonal head screw 4x 22� Screw ST 6,3 x 20 mm 8x
18� Nut M6 4x 23� Plug 4x
19� Bolt 1x
Parts overview:
1� Drive head 1x 8� Adapter for gear wheel 1x
2� Remote control 2x 9� Curved door arm 1x
3� Rail bracket 2x 10� C-bracket 2x
4� Hardwarebag 1x 11� Hanging bracket 2x
5� Wireless Wall Control
(ML810EV)
1x 12� Rail 1x
6� Header bracket 1x 13� MyQ Starter Kit
(ML810EV-Smart)
(ML1040EV-Smart)
1x
1x
7� Door bracket 1x 14� Photocells
(ML1040EV) 1x
Tool list:
Ladder Hacksaw
Marking pen Dierent drill bits for concrete
Pliers and (or wood (8, 6, 5, 4�5 mm)
Drilling machine Box wrench
Hammer Water level
Ratchet 10 mm / 13 mm Screwdriver
Measuring tape
To Next Page
