Chamberlain ML810EV User Manual

en 14
41
44
43
42
Optional Accessories
Specications
Declaration of conformity
Door dimensions und -weight
Always use Chamberlain accessories�
External products can cause malfunctions�
1� TX4RUNI 4-channel universal remote control
2� 128REV Wireless Wall Control 2-Channel
3� 747REV Keypad
4� 830REV MyQ Gateway
5� 1REV Quick release
6� 1702REV Quick release
7� 75REV Wired push button
8� FLA1-LED Flashing light
9� 771REV Photocells
10� 41REV Key switch (surface mount)
One piece doors ML810EV-/
Smart
ML1040EV-/
Smart
max� width (mm) 5000 5500
max� height (mm) 2250 2250
max� weight (kg) 110 140
Sectional doors ML810EV-/
Smart
ML1040EV-/
Smart
max� width (mm) 5000 5500
max� height (mm) 2150 2250
max� weight (kg) 110 140
Motor type DC gearmotor permanent
lubrication
Noise level 54dB
Drive Mechanism Belt
Length of Travel 2498 mm
Opening speed, up to 200 mm/s
Max� door weight 110 kg (ML810EV-/Smart)
140 kg (ML1040EV-/Smart)
Lamp On when door starts, o󰀨 2-1/2 minutes
after stop�
Door Linkage Adjustable door arm� Pull cord trolley
release
Safety, Personal Push button and automatic stop in
down direction� Push button and auto-
matic stop in up direction�
Electronic Automatic force adjustment
Electrical Transformer overload protector and low
voltage push button wiring�
Limit Device Mechanical RPM/Passpoint detector
Limit Adjustment Electronic
Soft-Start / Soft-Stop all model
Length (Overall) 3183 mm
Headroom Required min� 35 mm
Hanging Weight ~ 12 kg
Memory Registers 180
Operating Frequency: RX 433MHz (433�30MHz, 433�92MHz,
434�54MHz)
RX 868MHz (868�30MHz, 868�95MHz,
869�85MHz)
TX 865,125 MHz, 865,829 MHz,
866,587 MHz
<10 mW
Transmitter Model TX4REV-F / Wall Control Model 128REV
Transmitter / Wall Control
Frequency
868�30MHz, 868�95MHz, 869�85MHz /
433�30MHz, 433�92MHz, 434�54MHz
Sending power Transmitter
/ Wall Control
< 10 mW
Transmitter / Wall Control
Battery
3V CR2032
The manual consists of these operating instructions and the
declaration of conformity�
The radio equipment type (TX4REV-F, 128REV) is in compliance with
Directive 2014/53/EU and for UK with Radio Equipment Regulation SI
2017 No� 1209� The full text of the EU declaration of conformity is avai-
lable at the following internet address: https://doc�chamberlain�de/
Input Voltage 220-240 VAC, 50/60 Hz
Max� Pull Force 800 N (ML810EV-/Smart)
1000N (ML1040EV-/Smart)
Standby Power (door fully closed) 0�8 W
