Chevrolet 2010 New Sail New Technical Training
- Learner's Manual
3.4.8 Differential
1. Differential Housing Bolt
2. Differential Bearing
3. Differential Washer
4. Differential Housing
5. Odometer Driving Gear
6. Circlip
7. Planet Gear
8. Planet Gear Shaft
9. Half Axle Gear
10. Main Reduction Driven Wheel
3.5 Oil Level Inspection
Inspect the transaxle housing and its sealing area
for any leakage, dismount the oil level plug screw, and
inspect the oil level and the oil situation.
1. Run the engine until it reaches its normal working
temperature （ coolant temperature: 80-90°C
（176-194°F））.
2. Stop the engine and lift the vehicle.
3. Dismount the engine oil level plug screw and
inspect the oil level.
4. Oil should be able to spill a little from the engine
oil level plug screw hole.
5. If the oil level is too low, then recommended oil
should be filled in from the engine oil level plug
screw hole until oil starts to spill.
6. If oil is contaminated or discolored, then it should
