See the following online document for more information about network connections and interfaces:
• Cisco Modular Access Router CableSpecifications
Ethernet Connection
To reduce the risk of electric shock, the following ports must be connected through an approved network
termination unit with integral circuit protection if the port cabling is routed outdoors: ethernet. Statement 1044
Note
The IEEE has established Ethernet as standard IEEE 802.3. The routers support the following Ethernet
implementations:
• 1000BASE-T—1000Mb/s full-duplex transmission over a Category 5 or better unshielded twisted-pair
(UTP) cable. Supports the Ethernet maximum length of 328 feet (100 meters).
• 100BASE-T—100 Mb/s full-duplex transmission over a Category 5 or better unshieldedtwisted-pair
(UTP) cable. Supports the Ethernet maximum length of 328 feet (100 meters).
• 10BASE-T—10Mb/s full-duplex transmission over a Category 5 or better unshielded twisted-pair (UTP)
cable. Supports the Ethernet maximum length of 328 feet (100 meters).
See the Cisco Modular Access Router Cable Specifications document at Cisco.com for information about
Ethernet cables, connectors, and pinouts
Required Tools and Equipment for Installation and Maintenance
You need the following tools and equipment to install and upgrade the router and its components:
• ESD-preventive cord and wriststrap
• Number 2 Phillipsscrewdriver
• Phillips screwdrivers: small, 3/16-in. (4 to 5 mm) and medium, 1/4-in. (6 to 7mm)
• To install or removemodules
• Screws that fit yourrack
• Wire crimper
• Wire for connecting the chassis to an earthground:
• 6 AWG
Hardware Installation Guide for the Cisco 1100 Terminal Gateway
17
Prepare for Router Installation
Ethernet Connection
