Configure the Busy Lamp Field on a Key Expansion Module
You can configure the busy lamp field on a key expansion module line so that the user can monitor a coworker's
availability to receive a call.
Before you begin
Access the phone administration web page. See Access the Phone Web Page, on page 92.
Procedure
Step 1 Select Voice > Att Console.
Step 2 Select a key expansion module line key.
Step 3 Enter a string in this format:
fnc=blf;sub=xxxx@$PROXY;usr=8888@$PROXY.
Where:
• fnc= blf means function=busy lamp field
• sub= the URI to which the SUBSCRIBE message is sent. This name must be identical to the name defined
in the List URI: sip: parameter. xxxx is the name that is defined in List URI: sip: parameter. Replace
xxxx with the exact defined name. $PROXY is the server. Replace $PROXY with the server address or
name.
• usr= the BroadSoft user being monitored by BLF with 8888 as the phone being monitored. Replace 8888
with the exact number of the monitored phone. $PROXY is the server. Replace $PROXY with the server
address or name.
Step 4 (Optional) To enable the busy lamp field to work with both speed dial and call pickup enter a string in the
following format:
fnc=blf+sd+cp;sub=xxxx@$PROXY;usr=yyyy@$PROXY.
Where:
sd= speed dial
cp= call pickup
You can also enable busy lamp field only with call pickup or speed dial. Enter the string in the following
format:
fnc=blf+cp;sub=xxxx@$PROXY;usr=yyyy@$PROXY
fnc=blf+sd;sub=xxxx@$PROXY;usr=yyyy@$PROXY
Step 5 Click Submit All Changes.
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
105
Phone Accessories
Configure the Busy Lamp Field on a Key Expansion Module
