2-56
Cisco Integrated Services Router Hardware Installation Guide
Chapter 2 Installing the Router
Installing the Cisco 860, 880, 890 ISR
To install the SIM cards, follow these steps:
Step 1 Open the door covering the SIM card slots.
a. Insert the tip of the screw driver into the upper latch and gently disengage it as shown in the figure.
b. Remove the door as shown.
Step 2 To insert a SIM card into the SIM 0 slot, hold the SIM card with the contacts facing up as shown and
gently push the card into place until it locks in.
Step 3 To insert a SIM card into the SIM 1 slot, hold the SIM card with the contacts facing down as shown and
gently push the card into place until it locks in.
Step 4 Reattach the door.
a. Insert the door’s bottom latches as shown.
b. Insert the door’s upper latch into place as shown.
Installing the Cisco 880G for 3.7G (HSPA+)/3.5G (HSPA) ISRs
To install the C881G+7-K9, C886VAG+7-K9, C887VAG+7-K9, C887VAMG+7-K9, C888EG+7-K9,
C881GW+7-A-K9, C881GW+7-E-K9, C887VAGW+7-A-K9, and C887VAGW+7-E-K9 ISRs, follow
the instructions in the “Installing the Cisco 860, 880, and 890 Series Routers” section on page 2-40.
However, the instructions for connecting the 3G card in the hardware installation guide do not apply
because these ISRs do not have a slot for adding a 3G card. Instead, a 3G modem is embedded in the
router.
