Cisco ASR-920-24SZ-IM User Manual

DETAILED STEPS
Step 1
Connect one end of a shielded mini-coax cable to the GPS unit.
Step 2
Connect the other end of the shielded mini-coax cable to the 10-Mhz or 1-PPS port on the RSP of the Cisco
ASR-920-24SZ-IM Router.
Connecting a Cable to the Output 10-Mhz or 1-PPS Interface
SUMMARY STEPS
1.
Connect one end of a shielded mini-coax cable to the Slave unit.
2.
Connect the other end of the shielded mini-coax cable to the 10-Mhz or 1-PPS port on the RSP of the
Cisco ASR-920-24SZ-IM Router.
DETAILED STEPS
Step 1
Connect one end of a shielded mini-coax cable to the Slave unit.
Step 2
Connect the other end of the shielded mini-coax cable to the 10-Mhz or 1-PPS port on the RSP of the Cisco
ASR-920-24SZ-IM Router.
Connecting a Cable to the ToD Interface
SUMMARY STEPS
1.
Connect one end of a straight-through Ethernet cable to the GPS unit.
2.
Connect the other end of the straight-through Ethernet cable to the ToD or 1-PPS port on the RSP of the
Cisco ASR-920-24SZ-IM Router.
DETAILED STEPS
Step 1
Connect one end of a straight-through Ethernet cable to the GPS unit.
Step 2
Connect the other end of the straight-through Ethernet cable to the ToD or 1-PPS port on the RSP of the Cisco
ASR-920-24SZ-IM Router.
For instructions on how to configure clocking, see the Cisco ASR 920 Series Aggregation Services Routers
Configuration Guide.
Note
Cisco ASR-920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M Aggregation Services Router Hardware Installation
Guide
113
Installing the Router
Connecting Timing Cables
