CHAPTER 5
Troubleshooting
This chapter provides information about troubleshooting issues, if any, on the Cisco ASR 920-24SZ-IM,
ASR-920-24SZ-M, ASR-920-24TZ-M Router:
•
Pinouts, page 127
Pinouts
The sections describe the pinouts for the Cisco ASR 920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M
Router interfaces.
BITS Port Pinouts
BITS port is supported only on Cisco ASR-920-24SZ-IM Router.Note
The table below summarizes the BITS port pinouts.
Table 17: BITS Port Pinouts
DescriptionDirectionSignal NamePin
Receive RingInputRX Ring1
Receive TipInputRX Tip2
Not used
——
3
TX RingOutputTX Ring4
TX TipOutputTX Tip5
Not used
——
6
Cisco ASR-920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M Aggregation Services Router Hardware Installation
Guide
127
