Step 5 Connect the interface cables.
Mounting the Controller on a Wall
Do not wall-mount the device with its front panel facing up. Following safety regulations, wall-mount the
device with its front panel facing down or to the side to prevent airflow restriction and to provide easier access
to the cables.
Note
Read the wall-mounting carefully before beginning installation. Failure to use the correct hardware or to
follow the correct procedures could result in a hazardous situation to people and damage to the system.
Statement 378.
Warning
Wall mounting screws are not supplied. Installer must supply proper screws in accordance with local codes.
Controller wall mount holes located on the bottom of the enclosure fit standard #6 or M3 Pan Head screw.
The type of screw used to mount to wall should follow local guidelines for wall type and material.
Note
To mount the controller on a wall using mounting screws, follow these steps:
Procedure
Step 1 Mark the location of the mounting screws on the wall. Use the mount hole locations on the back of the controller
for placement of the mounting screws. Mounting screw spacing is 6 1/8 inch (155.4 mm).
Step 2 Install two screws and tighten until the top of the screws are 1/8 inch (3 mm) from the wall (leaving enough
room for the back panel to slide onto the screws firmly).
Step 3 Place the controller onto the mounting screws and slide it down until it lock into place, as shown in figure
below:
The front panel of the controller should be facing down.
Note
Cisco Catalyst 9800-L Wireless Controller Hardware Installation Guide
15
Installing the Cisco Catalyst 9800-L Wireless Controller
Mounting the Controller on a Wall
