Installing an SSD Module
This section provides an overview of an SSD module installation.
• Ensure that you are using proper static discharge techniques such as a wrist strap and static mat.
• Ensure that the device is powered down before performing the removal or installation of an SSD module.
Caution
Before you begin
Ensure the device is powered off.
Procedure
Step 1 Remove the two screws (1) holding the cover of the SSD module slot as shown in the following figure. Retain
these screws for future use.
Figure 24: SSD Module Cover
Screws1
Step 2 Insert the SSD module into the slot in the panel such that the previously removed screws (1) align with the
screw holes (2), as shown in the following figure.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
66
SSD Module
Installing an SSD Module
