Cisco Firepower 2100 Series Hardware Installation Guide

SFP transceiver
(Optional; in package if ordered)
4One power cord (country-specific)
See Power Cord Specifications, on page 37 for
the list of supported power cords.
3
One ground lug kit (part number 69-100359-01)
• One #6 AWG, 90 degree, #10 post ground
lug (part number 32-0608-01)
• Two 10-32 x 0.38-inch Phillips screws
6Two rack-mount brackets (part number
700-106374-01) and six Phillips 8-32 x
0.281-inch screws (part number 48-101518-01)
5
Cisco Firepower 2100
This document has a URL pointing to the
hardware installation guide, a URL pointing the
regulatory and safety guide, and a QR code and
URL pointing to the Getting Started Guide.
8Cable management bracket kit (part number
69-100376-01)
• Two cable management brackets (part
number 700-106377-01)
• Four 8-32 x 0.375-inch Phillips screws (part
number 48-2696-01)
(Optional; in package if ordered)
7
—Rack-mount screws:
• Four 12-24 x 0.75-inch Phillips screws (part
number 648-0440-01) for securing the
chassis to your rack
• Four 10-32 x 0.75-inch Phillips screws (part
number 48-0441-01) for securing the chassis
to your rack
• Four M6 x 1 x 19-mm Phillips screws (part
number 48-101022-01) for securing the
chassis to your rack
9
The following figure shows the package contents for the Firepower 2130 and 2140. The contents are subject
to change and your exact contents will contain additional or fewer items depending on whether you order the
optional parts. See Product ID Numbers, on page 34 for a list of the product IDs (PIDs) associated with the
2130 and 2140 package contents.
Cisco Firepower 2100 Series Hardware Installation Guide
6
Overview
Package Contents
