Cisco Firepower 2100 Series Hardware Installation Guide

Cable distance
Half the
distance
specified by
the IEEE
standard.
Note
Modal bandwidth
(MHz/km)
Core diameter (microns)
5 kmSingle modeG.652Cable and operating
distance
1-Gb Network Module with Hardware Bypass
The following figure shows the front panel view of the 1-Gb network module with hardware bypass
(FPR-NM-8X1G-F). Pair ports 1 and 2, 3 and 4, 5 and 6, and 7 and 8 to form hardware bypass paired sets.
Make sure you have the correct firmware package and software version installed to support this network
module. See Cisco FXOS Troubleshooting Guide for the Firepower 1000/2100 with Firepower Threat Defense
for the procedure to verify your firmware package and software version. See Cisco Firepower 2100 ASA
Platform Mode FXOS Configuration Guide for the procedure to upgrade the firmware package for the Firepower
2100 running ASA with FXOS.
Note
Figure 18: FPR-NM-8X1G-F
Cisco Firepower 2100 Series Hardware Installation Guide
26
Overview
1-Gb Network Module with Hardware Bypass
