51
English
Owner’s manual
Power Output : 18W RMS x 4 Channels at 4Ω and 1% THD+N
Signal to noise Ratio : 74dBA (reference : 1W into 4Ω )
※ Specifications and designs are subject to change without notice for further improvement.
unit : inch (mm)
9. SPECIFICATIONS
GENERAL
Power source voltage
14.4V DC
(10.8 to 15.6V allowable)
Ground Negative
Current consumption 4.0A(1W)
Auto antenna rated current 500mA less
Dimension of the Main Unit 7.0"(W) x 1.9"(H) x 6.2"(D)
Weight of the Main Unit 1.8kg
Dimension of the Remote Control Unit 2.0"(W) x 0.8"(H) x 6.4"(D)
Weight of the Remote control Unit 90g (including battery)
FM TUNER
Frequency range 87.9MHz to 107.9MHz
Quieting sensitivity 20dBf
Limiting sensitivity 15dBf
Stereo separation 20dB (1kHz)
Frequency response 100Hz to 7kHz
AUDIO
AMPLIFIER
Maximum power output 50W x 4ch
Speaker impedance 4 ohm (4 to 8 ohm)
MP3 / WMA
Sampling rate
MPEG1 44.1kHz/48kHz/32kHz
MPEG2 22.05kHz/24kHz/16kHz
MPEG1 32kbps to 320kbps
Bit rate MPEG2 8kbps to 160kbps
(VBR)
Logical Format
ISO9660 level1, 2
JOLIET or Romeo
DVD PLAYER
System
Digital versatile disc system with
CDDA capable
Usable discs DVD video disc, Compact disc
Frequency response 17Hz to 20kHz(CD)(+3/-3dB)
Separation 60dB
Distortion 0.5%
AM TUNER
Frequency range 530kHz to 1710kHz
Usable sensitivity 40dBuV
LCD MONITOR
Screen size 3.5inch wide type
Display method Transmission type
TN QVGA TFT LCD
Drive method
TFT(thin-film transistor)
active matrix driving
Pixels 336,960 (1440 x 234)
To Next Page
