Clarion VRX385USB User Manual

57
English
Owner’s manual
58
English
Owner’s manual
2. Power Supply Lead
15A
Battery
Yellow
Fuse Box
Filter &
Black
Violet
Violet / Black
Red
Grey
Green
Blue
Violet / White
Blue / White
Orange / White
Yellowish Green
Grey / Black
Green / Black
White
White / Black
Ground
Rear-Right(+)
Front-Right(+)
Front-Right(-)
Front-Left(+)
Front-Left(-)
Amp Remote On
Illumination
Auto Antenna
Parking Brake
Reverse
Rear-Right(-)
Rear-Left(+)
Rear-Left(-)
ACC
Electrical Connection
1. Wire Connection
Refer to the
next pages
6 Ch Amp
VTR
Video
Right
Left
Yellow
Red
Black
Black
Black
Brown
Green
Grey
Black
Black
Grey
Black
Blue
Grey
Red
White
Red
White
Red
White
Red
White
Yellow
Yellow
Visual-in(for camera)
OEM Remote
Tel Mute
iPod
Black
Antenna
USB Cable
Red
White
Rear Side
Monitor
Wireless Head phone
Visual
Input
Video
Audio(L)
Audio(R)
}
2Zone
Output
}
Subwoofer
Output
Right
Left
}
Rear
Audio
Output
Right
Left
}
Front
Audio
Output
Right
Left
}
※ Disconnect the Negative(-) power cable from the battery before installation.
※ The RCA pins and connector cables are sold separately.
※ To activate "Auto Mute-On when receiving phone call", connect right wire to the dedicated
connector in the vehicle.
