ComAp InteliGen NT BaseBox User Manual

IGS-NT Communication Guide
88
7.2.8 Time delay
Insert time delay before serving next part of SMS command.
Syntax:
d T
d … command
T … time delay in sec (in range 1 to 600)
Example:
#5:accesscode d 10
Request 10 sec delay before serving next SMS command.
Returncode:
d_ok … time delay was successful performed
d_over … requested time delay is out of range (1 to 600 sec)
Note: Any other SMS messages are not served during time delay!
7.2.9 Remote switches (IG/IS-NT only)
Set or reset RemoteControl1-8 output.
Syntax:
s 1/0
s … command
1/0 … set/reset
Example:
#5:accesscode p0, s1 1
Enters password p0 and sets RemoteControl1 output.
Returncode: p_OK,s_OK
7.2.10 ExtValues (IG/IS-NT only)
Enters value to ExtValue.
Syntax:
e xxx
e … command
xxx … value
Example:
#5
Message is addressed to controller with address 5.
Returncode:
?=(p <user:>passwd,r comm_obj,w com_obj val,c cmd_num,d sec,a,sx y,ex y,?)…... .....
list of supported SMS commands
Note: Return code is not separated to more message.

ComAp InteliGen NT BaseBox Specifications

General

Model	InteliGen NT BaseBox
Digital Inputs	8
Analog Inputs	4
Analog Outputs	2
Operating Temperature	-20 to +70 °C
Protection Class	IP20
Communication Ports	RS232, RS485, Ethernet
Humidity	95% non-condensing
Supported protocols	Modbus, CAN, J1939
Storage Temperature	-40 to +85 °C
