INSTRUCTIONS FOR TECHNICAL PERSONNEL
33
INSTALLATION
During the installation keep the machine leveled in order to ensure proper
functioning (angle of inclication is maximum 2 degrees). To prevent damage
caused by the release of vapors from the accessories, ensure that any adjacent
equipment will not be damaged by these vapors.
After test-running the machine, check that the temperatures used are the
recommended ones at 55°C for washing and 85°C for rinsing.
1) ELECTRICAL CONNECTION:
The electrical safety of this equipment is only assured if it is connected as
follows.
It is necessary to connect the equipment to an effective earthing as specified
by the electrical safety regulations in force. Check that this basic requirement
is complied with, in case of any doubt ask for a careful check of the
installation by a qualified personnel.
In the case the earthing is not efficient there will be a dispersion due to the
suppresser.
The machine shall be included in a correctly dimensioned equipotential,
whose effectiveness is to be very tight in accordance to the procedures set for
in the applicable safety standards. The connection shall be performed through
a screw marked by a plate near the rear side of the appliance.
The manufacturer declines any responsibility for any damages caused by lack
of an effective ground installation. For the electrical power supply have
available a wall circuit breaker switch with multiple phase protection
according the following table with contact aperture distance, equal to or not
exceeding 3mm and a supply cable no less than 2.5mm².
model Supply 380V 3N Supply 220V/3 Supply 220V/1
C1000E 20A 32A 50A
C1300E 20A 32A 63A
For other supplies the cable cross section and the circuit breaker switch must
be calculated according to voltage and length of cabling. If cabling too long
adjust cable size to Amp rating; do not pull on supply cable or install it under
tension. If cable needs to be replaced use type H07RN-F.
