Crown K1 Service Manual

K Series Service ManualRev A.
Exploded View Parts 7-5
©1999 Crown International, Inc.
Item # Description Part # (CPN) Qty. Notes
7.3 Front Panel Assembly
Refer to figure 7.2 for Exploded View
1 Bridge Rect. PWA 100444-X 1 See 6.9
2 Bracket, Transformer Mounting 100124 1
3 Power Transformer, K2 102236-1 1 w/connectors
Power Transformer, K1 H43525-7 1 w/connectors
4 Display PCA 102552-X 1 See 6.10
5 Knob, K2 D 8959-5 2
6 Rubber Washer, Toroid A10659-6 1
- Rubber Dampening Pad 102243-1 1 K1
7 Bridge, 35A 400V Wire Lead C10246-4 2 Qty 1 for K1
8 Lock Washer, #8 Internal Star A10094-6 1
9 Screw, 8-32 x .812 PNHD T20 A12148-70813 3
10 Handle F12722-9 2
11 Switch, Rocker DPDT 10A 100222-1 1
12 Screw, 1/4-20 x 2.0 FLTHD T27 A12149-72532 1
13 Belleville Washer, #8 A10098-3 2
14 Screw, 8-32 x .5 UC FLTHD T15 100331-70808 6
15 Front Panel F12717-9 1
16 Overlay, Set, K2 Front Panel 102181-X 1
16 Overlay, Set, K1 Front Panel 102183-X 1
17 5K Ohm Vol Pot Hardware C10245-6 2 Pot w/Hrdwr
18 Feet, Selfstick Black C 3342-0 2

Crown K1 Specifications

General

Signal to Noise Ratio	> 100 dB
Total Harmonic Distortion	<0.05%
Input Sensitivity	1.4V
Weight	22 lbs (10 kg)
Channels	2
Input Impedance	20 kOhms balanced, 10 kOhms unbalanced
Cooling	Convection cooled
Frequency Response	20Hz - 20kHz
Dimensions	19" x 3.5" x 11.5" (483 x 89 x 292 mm)
