8-4
8. OPERATING THE TRACTOR
Ex2900 / 3200 Operator's Manual
2. Raising (Unfolding) the Roll-Over Protective Structure (ROPS)
1. Pull out the cotter pin from each of the insert pins on
both sides of the Roll-Over Protective Structure
(ROPS).
(A) Cotter pin
(B) Insert pin
2. Pull out the insert pins from both sides of the Roll-Over
Protective Structure (ROPS).
3. Raise (unfold) the Roll-Over Protective Structure
(ROPS).
4. There are unfolded Roll-Over Protective Structure
(ROPS) retaining holes on both sides of the raised
Roll-Over Protective Structure (ROPS). Install the
insert pins into these holes.
5. There are insert pin jam holes on both ends of the
insert pin. Install the cotter pins into these holes.
NOTE:
●To secure the play-absorbing vibration-insulating
rubber block, pull the upper bolt to the near side and
insert the pins.
A3013706
(A)
(B)
