-14-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0160 Arm Assembly, Control 1
2 603-04184 Bracket, Hydro Neutral 1
3 703-05315 Bracket, Hydro Dump Mtg, 1
4 730-05316 Bracket, Hydro Dump Actuator 1
5 703-2441 Arm, Neutral 2
6 710-0106 Screw, Hex Cap, 1/4-20 x 1.25 1
7 710-04171 Screw, Special Hex Cap, 5/16-24 x .625 1
8 710-0809 Screw, Hex Wash TT-Tap, 1/4-20 x 1.25 2
9 711-04220 Pin, Clevis, .25 x 2.38 1
10 712-0324 Nut, Hex Top Lock, 1/4-20 1
11 714-0104 Pin, Internal Cotter 1
12 716-0111 Ring, Snap, .875 Shaft 1
13 723-3014 Filter, Oil 1
14 727-04064 Tube, Hydro Inlet 1
15 727-3002
721-3001
Connector, w/O-Ring
O-Ring, 3/8 OD Tube
2
2
16 732-3119 Spring, Extension, .5 OD x 1.97 1
17 736-0176 Washer, Flat, .25 x .93 x .120 Thk 2
18 737-3022 Nipple, Oil Filter 1
19 750-0918 Spacer, Centering 1
20 710-3180 Screw, Hex Cap, 5/16-18 x 1.75 GR5 2
NEUTRAL LINKAGE, HYDRAULIC PICKUP AND RETURN TUBES
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
15
17
To Next Page
