Cub Cadet GT 2186 User Manual

-8-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0272 Pivot Assembly 1
2 710-0599 Screw, Hex Wsh Hd Tapp, 1/4-20 x .5 2
3 710-3170 Screw, Ball, 5/16-18 x.56 1
4 712-0271 Nut, Hex Sems, 1/4-20 1
5 712-3004A Nut, Hex Flange Lock, 5/16-18 GR5 1
6 712-3027 Nut, Hex Flange Lock, 1/4-20 1
7 714-0104 Pin, Internal Cotter 2
8 727-3090 Cylinder, Damper 1
9 732-3094 Spring, Compression, .63 ID x 2 1
10 732-3118 Spring, Extension, 3/8 OD x 1.44 1
11 736-3092 Washer, Flat, .265 x 1 x .030 1
12 738-0560 Bolt, Shoulder, .374 Dia x 1.375 1
13 747-3304 Rod, Front Control 1
14 747-3309 Rod, Rear Hydro Control 1
15 748-3070A Plate, Cruise 1
16 750-0434 Spacer, Split Tubing, .375 ID x 1.04 1
TRANSMISSION CONTROLS

Cub Cadet GT 2186 Specifications

General

Brand	Cub Cadet
Model	GT 2186
Category	Tractor
Language	English
