-20-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 651-3001 Muffler Assembly 1
2 703-3099 Shield, Muffler Tube 1
3 703-2632 Baffle, RH Heat 1
4 710-1268 Screw, Hex Wsh Hd Tap, #10-16 x .38 2
5 710-0539 Bolt, Eng Mount, 3/8-24 x 1.75 GR5 4
6 KH-M-0841080 Nut, Hex Flange 4
7 712-3004A Nut, Hex Flange Lock, 5/16-18 3
8 712-3054 Nut, Hex Lock, 3/8-24 4
9 736-0105 Washer, Bell, .380 x .88 x .062 4
10 751-10026 Tube, Exhaust 1
11 759-3744 Arrestor, Spark 1
12 KH-24-041-02 Gasket, Exhaust 2
13 710-3209 Screw, Hex Cap, M6 x 1 x 10 4
14 736-0142 Washer, Flat, .281 x .5 x .06 5
15 710-0351 Screw, Truss Hd Tapp, #10 x .5 1
16 703-2631 Baffle, LH Heat 1
ENGINE MOUNTING AND MUFFLER
