Cub Cadet GT 2186 User Manual

-38-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 747-04196 Rod, Lift Link 1
2 703-2234 Bracket, LH Hanger 1
3 703-2804 Plate, Bearing Mounting 2
4 703-2832 Link, RH Lift 1
5 703-2833 Link, LH Lift 1
6 711-3319 Ferrule, Adjustment 1
7 712-0431 Nut, Hex Flange Lock, 3/8-16 6
8 712-3048 Nut, Hex Jam, 1/2-13 GR5 1
9 712-3083 Nut, Hex Insert Lock, 1/2-13 1
10 714-0145 Pin, Internal Cotter 2
11 736-0326 Washer, Flat, .5 x 1.5 x .15 3
12 736-3069 Washer, Flat, .531 x .875 x .15 2
13 738-0430 Bolt, Shoulder 2
14 738-0507B Bolt, Shoulder 3
15 747-3236A Rod, Lift Assist 1
16 738-0129 Bolt, Shoulder, 3/8-16: .5 x 2.0 1
17 732-3094 Spring, Compression, .63 ID x 2.0 1
18 726-0209 Tie, Cable 1
IMPLEMENT LIFT HANGER
1
2
3
4
5
6
8
9
10
11
12
13
14
3
7
7
7
11
11
12
13
14
14
15
16
17
7
10
18
