-7-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0064 Arm Assy, Lower Steering 1
2 603-0250 Segment Assy, 18T Steering 1
3 619-04079
737-3000
748-0108
748-3007A
Housing Assy,
Fitting, Grease, 3/16 Drive Type
Bearing, Flange, .503 ID
Bearing, Bronze Flange, .75 ID
1
1
1
2
4 631-04008 Wheel, Steering, Soft Grip 1
5 710-0751 Screw, Hex Cap, 1/4 - 20 x .62, GR5 2
6 710-1260A Screw, Hex Wash. Hd. Tapp
5/16 - 18 x .75
4
7 712-0237 Nut, Hex Center Lock, 5/16-18 1
8 712-0711 Nut, Hex Jam, 3/8-24 GR2 4
9 712-3012 Nut, Hex Slotted, 1/2-20 GR5 1
10 712-3027 Nut, Hex Flange Lock, 1/4-20 2
11 712-3054 Nut, Hex Lock, 3/8-24 GR5 4
12 714-3004 Pin, Cotter, 3/32 Dia x 1.25 1
13 717-04086 Pinion, Steering 1
14 722-3019 Gasket, Steering 1
15 723-0156 Joint, Ball, 3/8-24 4
16 731-04532 Cover, Steering Wheel 1
17 736-0272 Washer, Flat, .510 x 1 x .06 Thk 1
18 736-0351 Washer, Flat, .760 x 1.5 x .03 Thk 1
19 736-04062 Washer, Flat, .344 x 1.5 x .1 Thk 1
20 736-0921 Washer, Lock, 1/2 1
21 736-3013 Washer, Flat, .531 x 1 x .027 Thk 1
22 738-04064 Shaft, Steering 1
23 741-3025 Bearing, Flange 1
25 747-3171 Rod, Tie 2
STEERING
