Cub Cadet Yanmar Ex32002 User Manual

Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198220-42101 HOUSING, HYDRAULIC 1
2 CY-23876-010000 PLUG PT1/8,SCREW 1
3 CY-24550-045300 BUSH 2
4 CY-1A8160-42150 PACKING 1
5 CY-1A8160-42190 BOLT 10X50,REAMER 2
6 CY-194850-42500 CAP, OIL 33 1
7 CY-1A7335-42810 TOP LINK HINGE 1
8 CY-198223-43200 HEAD, CYLINDER ASSY 1
9 CY-198220-45920 PLUG 3/4-16UNF 1
10 CY-23414-190000 PACKING -19 1
11 CY-23876-010000 PLUG PT1/8,SCREW 5
12 CY-194310-46350 POPPET, CHECK 1
13 CY-194310-46380 SPRING 1
14 CY-194310-46730 PLUG 14 1
15 CY-23414-140018 GASKET 14 1
16 CY-24315-000110 O-RING 1B P-11.0 3
17 CY-24325-000600 O-RING 1B G-60.0 1
18 CY-24351-020300 O-RING 1A 2030 1
19 CY-26013-100302 BOLT M10X 30 2
20 CY-26013-100352 BOLT M10X 35 1
21 CY-26013-100452 BOLT M10X 45 1
22 CY-26013-120302 BOLT W/WASHER M12X30 4
23 CY-26013-120502 BOLT M12X 50 4
24 CY-198223-42270 BREATHER KIT 1
25 CY-198220-45920
PLUG 3/4-16UNF (NOT FOR SUB CONTROL
VALVE TYPE
)
2
26 CY-198220-45920
PLUG 3/4-16UNF (NOT FOR SUB CONTROL
VALVE TYPE
)
1
27 CY-23414-190000
PACKING -19 (NOT FOR SUB CONTROL VALVE
TYPE
)
2
28 CY-23414-190000
PACKING -19 (NOT FOR SUB CONTROL VALVE
TYPE
)
1
FIG. 69. HYDRAULIC CYLINDER CASE
109
Copyright 2007 Cub Cadet Yanmar LLC
