Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-194191-13350 SPACER 20X30X1.6 1

2 CY-1A8160-27360 SHAFT, RANGE SHIFT 1

3 CY-1A8160-27380 ARM, RANGE SHIFT 1

4 CY-1A8160-27430 SHIFT FORK, RANGE 1

5 CY-1A8160-27440 FORK SHAFT, RANGE 1

6 CY-1A8160-27450 BOLT, SWITCH 2

7 CY-194680-27540 SPRING, FORK LOCK 1

8 CY-22190-080002 SEAL WASHER 8S 1

9 CY-22242-000200 CIRCLIP 20 1

10 CY-22351-035032 SPRING PIN 3.5X32 1

11 CY-22351-035032 SPRING PIN 3.5X32 1

12 CY-22351-060032 SPRING PIN 6X32 1

13 CY-22351-060032 SPRING PIN 6X32 1

14 CY-24190-080001 BALL 1/4, STEEL 1

15 CY-24311-000150 O-RING 1A P-15.0 1

16 CY-26106-080162 BOLT M 8X 16 PLATED 1

17 CY-1A8160-27350 LEVER, RANGE SHIFT 1

FIG. 47. RANGE LEVER PARTS
