Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198230-17301 COLUMN, STEERING 1
2 CY-198230-17311 COLUMN ASSY 1
3 CY-194640-17340 BUSH, COLUMN 1
4 CY-198230-17340 SHAFT ASSY 1
5 CY-22242-000200 CIRCLIP 20 1
6 CY-22252-000420 CIRCLIP 42 1
7 CY-24104-060040 BALL BEARING 1
8 CY-1A8160-17500 VALVE ASSY, STEERING 1
9 CY-1A8160-17510 SEAL KIT 1
10 CY-198153-17630 BEARING COMP., NEEDLE 1
11 CY-26106-100202 BOLT M10X 20 PLATED 4
12 CY-26106-100202 BOLT M10X 20 PLATED 4
59
FIG. 27. POWER STEERING VALVE
Copyright 2007 Cub Cadet Yanmar LLC
