Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8160-11900 BRACKET KIT, FRONT WEIGHT 1
2 CY-198220-11350 PIN, WEIGHT LOCK 1
3 CY-198220-11520 BOLT 12X38 6
4 CY-198220-11900 BRACKET, FRONT 2
5 CY-194274-13580 SPRING WASHER 12 6
6 CY-194274-13580 SPRING WASHER 12 6
7 CY-194465-13650 BOLT M12X32 6
8 CY-22372-160000 SNAP PIN 16 2
9 CY-26716-120002 NUT 12 6
10 CY-26716-120002 NUT 12 6
177
FIG. 112. FRONT WEIGHT BRACKET EXTENSIONS (OPTIONAL)
Copyright 2007 Cub Cadet Yanmar LLC
