Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194145-27450 SPRING 1
2 CY-198220-27630 FORK, SHIFTER PTO 1
3 CY-198220-27640 SHAFT, FORK PTO 1
4 CY-198220-27650 ARM, SHIFT PTO 1
5 CY-198220-27700 SHAFT 1
6 CY-198220-27990 PLATE 1
7 CY-22190-100000 SEAL WASHER 10(BOLT) 1
8 CY-22351-060032 SPRING PIN 6X32 1
9 CY-22351-060032 SPRING PIN 6X32 1
10 CY-24190-100001 BALL 5/16, STEEL 1
11 CY-24311-000150 O-RING 1A P-15.0 2
12 CY-26106-080162 BOLT M 8X 16 PLATED 1
13 CY-26106-100252 BOLT M10X 25 PLATED 1
84
FIG. 49. P.T.O. SHIFTER
Copyright 2007 Cub Cadet Yanmar LLC
