Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194550-46300 VALVE, STOP 1
2 CY-194640-46620 BOLT, STOP 1
3 CY-194312-46630 HOLDER, VALVE (43) 1
4 CY-22117-080000 WASHER 8 1
5 CY-22351-040010 SPRING PIN 4X10 1
6 CY-24311-000120 O-RING 1A P 12.0 1
7 CY-24315-000090 O-RING 1B P- 9.0 1
8 CY-1A8160-46670 KNOB, STOP VALVE 1
9 CY-26716-100002 NUT 10 1
115
FIG. 74. STOP VALVE
Copyright 2007 Cub Cadet Yanmar LLC
