Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129403-42380 V-PULLEY(D=110) 1
2 CY-129211-42290 V-BELT 1
3 CY-129120-44741 FAN, COOLING (D=360) 1
4 CY-129030-44760 SPACER 1
5 CY-26106-060502 BOLT M 6X 50 PLATED 4
6 CY-129155-49801 THERMOSTAT (71) 1
7 CY-129150-49811 GASKET, (NON-ASB.) 1
8 CY-129795-49551 GASKET, (NON-ASB.) 1
9 CY-129350-49560 COVER, THERMOSTAT 1
10 CY-26306-080002 NUT 2
11 CY-129263-49610 PIPE, COOLING WATER 1
12 CY-129263-49710 PIPE, COOLING WATER 1
13 CY-124722-59050 CLAMP 9 2
14 CY-129263-49620 PIPE, COOLING WATER 1
15 CY-129263-49720 PIPE, COOLING WATER 1
16 CY-124722-59050 CLAMP 9 2
17 CY-119620-49290 DRAIN ASSY 1/4 1
21 CY-121450-42450 PLUG M16 1
22 CY-129054-42450 PLUG, M12X1.5 1
23 CY-124465-44950 GASKET 16 1
24 CY-124250-49351 THERMOMETER 1
25 CY-129150-49360 GASKET 10 1
26 CY-22190-120002 SEAL WASHER 12 1
27 CY-129486-42050 GASKET 1
28 CY-23414-080000 GASKET 8, ROUND 1
29 CY-26106-080122 BOLT M 8X 12 PLATED 1
30 CY-26106-080552 BOLT M 8X 55 PLATED 2
31 CY-26106-080602 BOLT M 8X 60 PLATED 1
32 CY-26106-080702 BOLT M 8X 70 PLATED 1
33 CY-129269-42000 PUMP ASSY, WATER 1
34 CY-129457-42050 PACKING 1
35 CY-129457-42121 PLATE 1
39 CY-129150-42301 FLANGE, PUMP 1
40 CY-24358-240310 O-RING 5 24031 1
42 CY-129054-42320 O-RING 1
43 CY-26577-060152 SCREW M 6X 15 3
44 CY-26106-060202 BOLT M 6X 20 PLATED 2
45 CY-26116-060162 BOLT 6X16 5
46 CY-119802-49113 JOINT 2
47 CY-23875-030000 PLUG PT3/8,STEEL 2
49 CY-129555-44750 STUD 2
FIG. 11. COOLING WATER SYSTEM
17
Copyright 2007 Cub Cadet Yanmar LLC
