Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-194150-01370 ADJUSTER 1

4 CY-158553-61050 PACKING, CASE 1

5 CY-158553-61070 PACKING 1

7 CY-129155-51280 O-RING S6 1

23 CY-129255-61410 NUT 1

24 CY-119807-61420 SPRING 1

25 CY-158552-61441 LEVER, REGULATOR 1

26 CY-129155-61460 BOLT, IDLE LIMIT 1

60 CY-119660-61901 RETAINER, SHAFT 1

64 CY-22190-120000 SEAL WASHER 12(BOLT) 1

66 CY-23887-120002 PLUG M12,HEX. 1

68 CY-26106-060102 BOLT 6X 10 PLATED 1

69 CY-26756-060002 LOCK NUT 6 1

78 CY-158552-61900 O-RING 1

83 CY-26106-060142 BOLT M 6X 14 PLATED 2

84 CY-26106-060142 BOLT M 6X 14 PLATED 4

85 CY-26106-060202 BOLT M 6X 20 PLATED 10

87 CY-129642-61060 COVER, CASE 1

130 CY-119653-77950 SOLENOID, STOP 1

131 CY-22137-080000 WASHER 8, POLISHED 1

132 CY-22417-160180 COTTER PIN 1.6X18 1

FIG. 13. GOVERNOR
