Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22140 NUT W/WASHER 8 2
2 CY-194990-22140 NUT W/WASHER 8 3
3 CY-194170-51210 GROMMET, 25 4
4 CY-198071-58810 GROMMET 8 1
5 CY-198448-60080 TRIM 40 1
6 CY-198448-60080 TRIM 40 2
7 CY-1A7260-60911 HINGE ASSY, HOOD 1
8 CY-1A7260-60580 SPRING, L.H. 1
9 CY-1A7260-60590 SPRING, R.H. 1
10 CY-1A7260-61080 PLATE, LOWER 1
11 CY-1A7260-61190 PIN, 1
12 CY-22272-000080 CIRCLIP E- 8 2
13 CY-1A7260-60950 STAND, A HOOD 1
14 CY-1A7260-60960 STAND, B HOOD 1
15 CY-1A7890-60980 CUSHION 1
16 CY-1A7340-61560 WEATHER STRIP, 180 2
17 CY-194440-61580 GROMMET, 21X46 2
18 CY-194167-61650 NUT, M5 2
19 CY-194167-61650 NUT, M5 4
20 CY-1A8160-61700 PLATE CMP, AIR SHIELD 1
21 CY-1A8160-61730 SUPPORT L.H., CMP 1
22 CY-1A8160-61740 SUPPORT R.H., CMP 1
23 CY-1A8160-61810 STAY,DB SIDE 2
24 CY-194555-61970 STRIP 2
25 CY-1A8160-62030 BRACKET L CMP, TANK 1
26 CY-1A8160-62040 BRACKET R CMP, TANK 1
27 CY-1A8160-62050 SUPPORT CMP, HOOD 1
28 CY-194330-62530 STOPPER, PEDAL 2
29 CY-1A8160-62540 STAND CMP, HOOD 1
30 CY-174570-63620 WEATHER-STRIP, 195 1
31 CY-198146-63660 STRIP 250, WEATHER 1
32 CY-22137-080000 WASHER 8, POLISHED 1
33 CY-22137-080000 WASHER 8, POLISHED 2
34 CY-22372-080000 SNAP PIN (JASO 8) 1
35 CY-22372-080000 SNAP PIN (JASO 8) 2
36 CY-22487-080300 PIN 8X 30 1
37 CY-22487-080300 PIN 8X 30 2
38 CY-26106-080162
BOLT M 8X 16 PLATED - S/N
F000155 & BELOW
21
38 CY-26106-080162
BOLT M 8X 16 PLATED - S/N
F000156 & ABOVE
19
39 CY-26106-060122 BOLT M 6X 12 PLATED 4
40 CY-198245-51210 GROMMET 25 1
41 CY-26106-080122
BOLT M 8X 12 PLATED - S/N
F000156 & ABOVE
2
143
FIG. 94. HOOD FRAME
Copyright 2007 Cub Cadet Yanmar LLC
