Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8160-71000 3P LINK KIT 1
2 CY-1A7335-71100 TOP LINK KIT 1
3 CY-1A7335-71230 PIN, TOP LINK 1
4 CY-1A7335-71240 PIN 1
5 CY-1A7335-71250 CAP 4
6 CY-1A7335-71410 LYNCH PIN ASSY 2
7 CY-1A7335-71500 TURNBUCKLE 1
8 CY-1A7335-71600 END 1
9 CY-1A7335-71700 END 1
10 CY-1A7335-71750 LOCK WASHER 1
11 CY-22351-050025 SPRING PIN 5X25 2
12 CY-1A7335-71410 LYNCH PIN ASSLY 3
13 CY-1A7335-72100 ADJ. LIFT ROD ASSY 1
14 CY-1A7335-71250 CAP 4
15 CY-1A7335-71410 LYNCH PIN ASSLY 1
16 CY-1A7335-72200 LINK 1
17 CY-1A7335-72230 TURNBUCKLE (LIFT LINK) 1
18 CY-198234-72550 PIN 1
19 CY-1A7335-72800 KIT 1
20 CY-22137-160000 WASHER 16, POLISHED 1
21 CY-22351-050022 SPRING PIN 5X22 2
22 CY-22417-320320 COTTER PIN 3.2X32 1
23 CY-24761-060000 FITTING, 6 1
24 CY-26756-200002 LOCK NUT M20 PLATED 1
25 CY-1A7335-72500 FIXED LIFT ROD ASSY 1
26 CY-1A7335-71410 LYNCH PIN ASSLY 2
27 CY-1A7335-72530 LINK 1
28 CY-198234-72550 PIN 1
29 CY-22137-160000 WASHER 16, POLISHED 1
30 CY-22417-320320 COTTER PIN 3.2X32 1
31 CY-1A7335-73400 LINK & CHAIN KIT 2
32 CY-1A7335-73100 DRAFT LINK 2
33 CY-1A7335-74600 CHAIN STABILIZER ASSY 2
34 CY-194197-74641 NUT, CHAIN 2
35 CY-198240-74641 PIN, SHACKLE 2
36 CY-198220-74670 BOLT CMP., CHK. CHAIN 2
37 CY-198220-74800 SWAY CHAIN, REAR COMP 2
38 CY-198220-75850 PLATE, SWAY CHAIN 4
39 CY-22217-140000 SPRING WASHER 14 2
40 CY-22360-180000 SNAP PIN 18 2
41 CY-22417-400250 COTTER PIN 4.0X25 2
42 CY-26716-140002 NUT M14 2
43 CY-198220-73140 COLLAR 2
44 CY-198220-73240 COLLAR 2
45 CY-198220-73250 SPRING 1
163
FIG. 104. THREE POINT LINK
Copyright 2007 Cub Cadet Yanmar LLC
