Cub Cadet Yanmar Ex32002 User Manual

Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
REF
NO.
PART NUMBER DESCRIPTION QTY
1 N/A MID PTO KIT, EX3200 1 34 CY-198220-27720 SHAFT, MID PTO SHIFT 1
2 CY-1A8160-26610 MID PTO, MISSION KIT 1 35 CY-198220-27840 SPRING 1
3 CY-194505-24160 NEEDLE 20/16 1 36 CY-198220-27850 SHAFT, MID PTO BRAKE 1
4 CY-194065-25340 WASHER 25X42X4.8 1 37 CY-198220-27860 LEVER, MID PTO BRAKE 1
5 CY-194640-25390 BALL BEARING 1 38 CY-194464-52190 SWITCH, SAFETY START 1
6 CY-194190-26351 WASHER 20X41X2.5 2 39 CY-22217-100000 SPRING WASHER 10 1
7 CY-198220-26570 WASHER 20.5*25*4 1 40 CY-22242-000250 CIRCLIP 25S 2
8 CY-198220-26711 CASE,MID PTO DRIVE 1 41 CY-22252-000520 CIRCLIP 52 1
9 CY-198220-26730 GASKET, CASE 1 42 CY-22262-000280 CIRCLIP 28 1
10 CY-198220-26740 CASE, SEAL 1 43 CY-22312-080120 PARALLEL PIN 8X12 2
11 CY-198220-26750 COVER 1 44 CY-22351-035028 SPRING PIN 3.5X28 1
12 CY-198220-26761 COVER, MID PTO CASE 1 45 CY-22351-035028 SPRING PIN 3.5X28 1
13 CY-198220-26771 GASKET, CASE COVER 1 46 CY-22351-050020 SPRING PIN 5X20 1
14 CY-198220-26790 SHOE. SHIFTER 1 47 CY-22351-050050 SPRING PIN 5X50 1
15 CY-198220-26800 GEAR, MID PTO DRIVE 1 48 CY-22351-060028 SPRING PIN 6X28 1
16 CY-198220-26810 SHAFT, IDLER 1 49 CY-22351-060028 SPRING PIN 6X28 1
17 CY-198220-26820 GEAR, IDLER 1 50 CY-22351-060028 SPRING PIN 6X28 1
18 CY-198220-26830 COLLAR 25*34*19.4 1 51 CY-22351-060028 SPRING PIN 6X28 1
19 CY-194190-26840 SPACER 25X36X1.6 1 52 CY-23491-140002 PLUG 14 1
20 CY-198220-26840 SHAFT, MID PTO DRIVE 1 53 CY-24161-202620 NEEDLE BEARING 2
21 CY-194850-26850 COVER ASSY, SHAFT 1 54 CY-24190-080001 BALL 1/4, STEEL 2
22 CY-194850-26870 SPRING, SHIFT COVER 2 55 CY-24311-000125 O-RING 1A P-12.5 1
23 CY-198220-26850 ACTUATOR 1 56 CY-24311-000125 O-RING 1A P-12.5 1
24 CY-198220-26860 STEEL PLATE 5 57 CY-24311-000160 O-RING 1A P-16.0 1
25 CY-198220-26870 SHOE. MID PTO BRAKE 4 58 CY-24321-001000 O-RING 1A G-100.0 1
26 CY-198220-26890 SLIDER, MID PTO 1 59 CY-26013-060122 BOLT M 6X 12 2
27 CY-198220-26910 SPRING 1 60 CY-26013-080162 BOLT W/WASHER M8X16 1
28 CY-198220-26930 PACKING KIT 1 61 CY-26013-080202 BOLT W/WASHER M8X20 6
29 CY-198220-26940 PACKING 18 1 62 CY-26013-080352 BOLT M 8X 35 5
30 CY-23414-180000 GASKET 18, ROUND 1 63 CY-26013-100852 BOLT W/WASHER 10X 85 2
31 CY-198230-27540 PLATE 2 64 CY-26716-100002 NUT 10 1
32 CY-198220-27600 SPRING 1 65 CY-933147-10350 SEAL QLF 25471121 1
33 CY-198220-27690 ARM, MID PTO SHIFT 1 66 CY-26013-101202 BOLT W/WASHER 10X120 1
173
FIG. 110. MID P.T.O. KIT 59A40014727 (OPTIONAL)
Copyright 2007 Cub Cadet Yanmar LLC
