Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-198220-26790 SHOE. SHIFTER 1

2 CY-198119-27150 COLLAR 1

3 CY-198212-27990 PLATE, KEEP 1

4 CY-1A8160-28210 SHAFT, MFWD 1

5 CY-1A8160-28220 GEAR, FRONT 35 1

6 CY-1A8160-28230 SHIFTER, FRONT 1

7 CY-194301-28280 SPRING 25.8 1

8 CY-1A8160-28310 SHAFT, MFWD SHIFT 1

9 CY-1A8160-28320 SHIFT ARM, MFWD 1

10 CY-1A8160-28360 CHANGE ARM, FRONT 1

11 CY-22252-000520 CIRCLIP 52 1

12 CY-22351-060032 SPRING PIN 6X32 1

13 CY-22351-060032 SPRING PIN 6X32 1

14 CY-24101-062054 BEARING #6205 1

15 CY-24101-063034 BALL BEARING 1

16 CY-24190-080001 BALL 1/4, STEEL 2

17 CY-24311-000160 O-RING 1A P-16.0 1

18 CY-24421-255210 OIL SEAL TC255210 1

19 CY-26106-080162 BOLT M 8X 16 PLATED 1

20 CY-198273-28520 KNOB, P BRAKE 1

FIG. 51. FRONT DRIVE
