3
4
6
5
3
4
7
2
8
6
CLICK!
20
• Please select an appropriate seat in the vehicle.
• If the ISOFIX anchorage points (6) in your car are difficult to
access, you should use the connect guides
(8)
provided in order
to avoid damaging the cover.
• If necessary attach the connect guides
(8)
provided with the
longer lug pointing upwards into both ISOFIX anchorage points
(6). In many cars it is more effective to install the connect guides
(8)
in an opposing direction.
• Unfold the support leg (2) until it locks.
• Release the lock of the ISOFIX connectors. Both locks can
be adjusted independently. Push both buttons (3)
and
(4)
simultaneously and pull the ISOFIX connectors out of the base
to the endstopper.
• The ISOFIX connectors (5) have to lock into the ISOFIX
anchorage points (6) with an audible "CLICK".
• Make sure that the seat stays firmly in place by trying to pull it
out of the ISOFIX connect guides.
• The green safety indicator (7) must be clearly visible on both
ISOFIX release buttons.
• Next, push the seat in the direction to the backrest until it is
fully aligned with the backrest.
INSTALLING IN VEHICLE
NOTE! If your vehicle does not have an i-Size seating position,
please check the vehicle typelist that is included.
NOTE! The ISOFIX anchorage points
(6)
are two metal lugs per
seat and are located between the backrest and the seat of the
car. If you are in any doubt, consult your car‘s instruction manual
for assistance.
NOTE! Do not put any objects in the foot area in front of the
child seat.
