D-Link DHP-W310AV User Manual

38D-Link DHP-W310AV User Manual
Section 3 - Conguration
Connecting to a Wireless Network
Using Windows
®
7
It is recommended to enable wireless security (WPA/WPA2) on your DHP-W310AV before conguring your wireless adapter. If you are joining an
existing network, you will need to know the security key or passphrase being used.
1. Click on the wireless icon in your system tray (lower-right corner).
2. The utility will display any available wireless networks in your area.
Wireless Icon

D-Link DHP-W310AV Specifications

General

Wi-Fi	No
Modulation	OFDM
Power plug	-
Ethernet LAN	Yes
PowerLine standard	HomePlug AV
Security algorithms	128-bit AES
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	200 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	FCC, CE EMC B, UL, CE LVD
Product color	White
LED indicators	LAN, Power
Current	0.1 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	4 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	42.4 mm
Width	61 mm
Height	68 mm
Weight	125.6 g
