D-Link DHP-W310AV User Manual

45D-Link DHP-W310AV User Manual
Section 3 - Conguration
Connecting to a Wireless Network
Using Windows
®
XP
Windows XP users may use the built-in wireless utility (Zero Conguration Utility). The following instructions are for Service Pack 2 users. If you are
using another company’s utility or Windows 2000, please refer to the user manual of your wireless adapter for help with connecting to a wireless
network. Most utilities will have a “site survey” option similar to the Windows XP utility as seen below.
Right-click on the wireless computer icon in your system tray (lower right corner
next to the time). Select View Available Wireless Networks.
If you receive the Wireless Networks Detected bubble, click on the center of the
bubble to access the utility.
or
The utility will display any available wireless networks in your area. Click on a
network (displayed using the SSID) and click the Connect button. The Wi-Fi
Conguration Card will list your device’s specic network, it will not be simply dlink.
If you get a good signal but cannot access the Internet, check your TCP/IP settings
for your wireless adapter. Refer to the Networking Basics section in this manual
for more information.

D-Link DHP-W310AV Specifications

General

Wi-Fi	No
Modulation	OFDM
Power plug	-
Ethernet LAN	Yes
PowerLine standard	HomePlug AV
Security algorithms	128-bit AES
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	200 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	FCC, CE EMC B, UL, CE LVD
Product color	White
LED indicators	LAN, Power
Current	0.1 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	4 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	42.4 mm
Width	61 mm
Height	68 mm
Weight	125.6 g
