D-Link DHP-W310AV User Manual

41D-Link DHP-W310AV User Manual
Section 3 - Conguration
Connecting to a Wireless Network
Using Windows Vista
®
Windows Vista® users may use the convenient, built-in wireless utility. Follow these instructions:
From the Start menu, go to Control Panel, and then click on Network
and Sharing Center.
The utility will display any available wireless networks in your area.
Click on a network (displayed using the SSID) and click the Connect
button. The Wi-Fi Conguration Card will list your device’s specic
network, it will not be simply dlink.
If you get a good signal but cannot access the Internet, check you
TCP/IP settings for your wireless adapter. Refer to the Networking
Basics section in this manual for more information.
Click Connect Anyway to continue.

D-Link DHP-W310AV Specifications

General

Wi-Fi	No
Modulation	OFDM
Power plug	-
Ethernet LAN	Yes
PowerLine standard	HomePlug AV
Security algorithms	128-bit AES
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	200 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Certification	FCC, CE EMC B, UL, CE LVD
Product color	White
LED indicators	LAN, Power
Current	0.1 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	4 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	42.4 mm
Width	61 mm
Height	68 mm
Weight	125.6 g
