D-Link DIR-506L User Manual

15D-Link DIR-506L User Manual
Section 2 - Installation
7. Tap on the Settings gear icon located on the right top corner of the
screen. Then, click Edit to enter your User Name and Password. Once
you nish, click Done to continue.
8. You can now use the SharePort Mobile app to access the les on your
USB storage drive.
Note: If you connect a USB storage drive with many les or with a large
capacity, it may take a while for the DIR-506L to scan and catalog
your les.

D-Link DIR-506L Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	1
USB version	2.0
Rack mounting	No
DHCP client	-
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2, WPS
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	22.3 mm
Width	102.9 mm
Height	79.8 mm
Weight	125 g
