D-Link DIR-632 User Manual

DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
For every Access Category the following fields are available:
Parameter Description
Aifsn
Arbitrary Inter-Frame Space Number. This parameter influences
time delays for the relevant Access Category. The lower the value,
the higher is the Access Category priority.
CWMin/CWMax
Contention Window Minimum/Contention Window Maximum. Both
fields influence time delays for the relevant Access Category. The
CWMax field value should not be lower, than the CWMin field
value. The lower the difference between the CWMax field value
and the CWMin field value, the higher is the Access Category
priority.
Txop
Transmission Opportunity. The higher the value, the higher is the
Access Category priority.
ACM
Admission Control Mandatory.
If selected, prevents from using the relevant Access Category.
Ack
Acknowledgment. Answering response requests while transmitting.
Displayed only in the Parameters of Access Point section.
If not selected, the router answers requests.
If selected, the router does not answer requests.
When you have configured the parameters, click the Change button.
Page 145 of 197

D-Link DIR-632 Specifications

Device Interface

LAN ports	8 10/100 LAN Ports
WAN port	1 10/100 WAN Port
device management	Internet Explorer v7 or Later; Mozilla Firefox v3.0 or Later; or other Java-enabled Browsers

Weight and Dimensions

item dimensions	230mm x 150mm x 33mm
packaging dimensions	276.9mm x 66mm x 205.8mm
item weight	272.2 grams
