DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Installation and Connection
Connecting to Web-based Interface
When you have configured your computer, you can access the web-based interface and configure
needed parameters (create a WAN connection, change the parameters of the wireless network,
specify the settings of the firewall, etc.).
1. Start a web browser (see the Before You Begin section, page 16).
2. In the address bar of the web browser, enter the IP address of the router (by default, the
following IP address is specified: 192.168.0.1). Press the Enter key.
Figure 15. Connecting to the web-based interface of the DIR-632 device.
3. On the opened page, enter the username and password for the administrator account in the
Login and Password fields correspondingly (by default, the following username and
password are specified: admin, admin). Then click the Enter link.
Figure 16. The login page.
!
If the error “ The page cannot be displayed ” (or “ Unable to display the page ”/“ Could not
connect to remote server ”) occurs upon connecting to the web-based interface of the router,
make sure that you have properly connected the router to your computer.
Page 30 of 197
