D-Link DIR-632 User Manual

DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Installation and Connection
PC with Wi-Fi Adapter
1. To connect via a WiMAX, 3G GSM or CDMA network: connect your USB modem to the
USB port
5
located on the back panel of the router.
!
If you need to connect or change a USB modem to another one when the router is powered
on, power off the device, connect the modem to the USB port, and power on the router.
2. Connect the power cord to the power connector port on the back panel of the router, then
plug the power adapter into an electrical outlet or power strip.
3. Turn on your PC and wait until your operating system is completely loaded.
4. Turn on your Wi-Fi adapter. As a rule, modern notebooks with built-in wireless NICs are
equipped with a button or switch that turns on/off the wireless adapter (refer to your PC
documents). If your PC is equipped with a pluggable wireless NIC, install the software
provided with your Wi-Fi adapter.
5 It is recommended to use a USB extension cable to connect a USB modem to the router.
Page 26 of 197

D-Link DIR-632 Specifications

Device Interface

LAN ports	8 10/100 LAN Ports
WAN port	1 10/100 WAN Port
device management	Internet Explorer v7 or Later; Mozilla Firefox v3.0 or Later; or other Java-enabled Browsers

Weight and Dimensions

item dimensions	230mm x 150mm x 33mm
packaging dimensions	276.9mm x 66mm x 205.8mm
item weight	272.2 grams
