D-Link DIR-632 User Manual

DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
UPnP
On the Advanced / UPnP page, you can enable and disable the UPnP function.
UPnP is a set of networking protocols designed for automatic configuration of network devices. The
UPnP function performs automatic configuration of the device's parameters for network
applications requiring an incoming connection to the router.
Figure 118. The Advanced / UPnP page.
If you want to enable the UPnP function in the router, select the Enabled checkbox and click the
Change button.
If you want to manually specify all parameters needed for network applications, deselect the
Enabled checkbox and click the Change button.
Page 150 of 197

D-Link DIR-632 Specifications

Device Interface

LAN ports	8 10/100 LAN Ports
WAN port	1 10/100 WAN Port
device management	Internet Explorer v7 or Later; Mozilla Firefox v3.0 or Later; or other Java-enabled Browsers

Weight and Dimensions

item dimensions	230mm x 150mm x 33mm
packaging dimensions	276.9mm x 66mm x 205.8mm
item weight	272.2 grams
