D-Link DIR-632 User Manual

DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
Creating 3G WAN Connection
If the PIN code check is enabled for the SIM card inserted into your USB modem, then prior to
creating a 3G WAN connection, proceed to the USB modem menu and enter the PIN code on the
page displayed (see the USB Modem section, page 168). Then proceed to the Net / WAN page,
click the Add button, and select the 3G value from the Connection Type drop-down list.
Figure 76. The page for creating a new connection. The General settings and 3G sections.
Parameter Description
General settings
Provider
To automatically specify all settings required to connect to the
Internet, select your country and operator from the drop-down list.
To specify all settings independently, leave the Manually value.
Port Select the USB value.
Name
A name for connection for easier identification.
Enable
Select the checkbox to enable the connection.
Direction
The direction of this connection.
3G
Mode
The value of the field specifies the type of the network to which the
router connects. Leave the auto value to let the router connect
automatically to an available type of network, or select a needed
value from the drop-down list. For GSM USB modems only.
Page 96 of 197

D-Link DIR-632 Specifications

Device Interface

LAN ports	8 10/100 LAN Ports
WAN port	1 10/100 WAN Port
device management	Internet Explorer v7 or Later; Mozilla Firefox v3.0 or Later; or other Java-enabled Browsers

Weight and Dimensions

item dimensions	230mm x 150mm x 33mm
packaging dimensions	276.9mm x 66mm x 205.8mm
item weight	272.2 grams
