DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
Figure 123. The page for adding a static route.
You can specify the following parameters:
Parameter Description
Destination network A destination network to which this route is assigned.
Destination netmask
The destination network mask.
Gateway
An IP address through which the destination network can be accessed.
The field is displayed when the <Auto> value is selected from the Via
Interface drop-down list.
Metric
A metric for the route. The lower the value, the higher is the route
priority. Optional.
Via Interface
Select an interface through which the destination network can be
accessed from the drop-down list. If you have selected the <Auto>
value of this drop-down list, the router itself sets the interface on the
basis of data on connected networks.
Click the Save button.
To edit an existing route, click the relevant route link. On the opened page, change the needed
parameters and click the Save button.
To remove an existing route, click the relevant route link. On the opened page, click the Delete
button.
Page 155 of 197
