D-Link DIR-632 User Manual

DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
The following buttons are available on the page:
Control Description
Save
Click the button to save settings to the non-volatile memory. Please,
save settings every time you change the router's parameters.
Otherwise the changes will be lost upon hardware reboot of the
router.
Factory
Click the button to restore the factory default settings. Also you can
restore the factory defaults via the hardware RESET button (see the
Saving and Restoring Settings section, page 36).
Backup
Click the button and follow the dialog box appeared to save the
configuration (all settings of the router) to your PC.
Restore
Click the button to upload a previously saved configuration (all
settings of the router) from a file on your PC. Click the
Choose/Browse
7
button to select a previously saved
configuration file located on your PC.
Actions of the Save, Factory, and Backup buttons also can be performed via the top-page menu
displayed when the mouse pointer is over the System caption.
7 The name of the button depends upon the web browser that you use.
Page 183 of 197

D-Link DIR-632 Specifications

Device Interface

LAN ports	8 10/100 LAN Ports
WAN port	1 10/100 WAN Port
device management	Internet Explorer v7 or Later; Mozilla Firefox v3.0 or Later; or other Java-enabled Browsers

Weight and Dimensions

item dimensions	230mm x 150mm x 33mm
packaging dimensions	276.9mm x 66mm x 205.8mm
item weight	272.2 grams
